Product Details:
|
| Color: | Yelow | Fiber Type: | Single Mode |
|---|---|---|---|
| Length: | 1m | Connector: | LC UPC To LC UPC |
| Application: | FTTH | Connector Type: | LC |
| Operating Temperature: | -20~70°C | Return Loss: | ≥50dB |
| Insertion Loss: | ≤0.3dB | Fiber Count: | Duplex |
| Cable Diameter: | 3.0mm | ||
| High Light: | LC UPC Duplex Fiber Patch Cable,PVC 3.0mm 1m os2 sm fiber,1m single mode os2 fiber cable |
||
1m LC UPC To LC UPC Fiber Optic Patch Cord Duplex OS2 Single Mode PVC 3.0mm
LC-LC Uniboot Duplex OS2 SMF PVC (OFNR) 3.0mm Fiber Optic Patch Cable
The 9/125μm OS2 single mode bend insensitive fiber optic cable is less attenuation when bent or twisted compared with traditional optical fiber cables and this will make the installation and maintenance of the fiber optic cables more efficient. It can also save more space for your high density cabling in data centers, enterprise networks, telecom room, server farms, cloud storage networks, and any places fiber patch cables are needed.
This 9/125 OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G/400G Ethernet connections. It can transport data for up to 10km at 1310nm, or up to 40km at 1550nm.
| Fiber Grade | G.657.A1 (Compatible with G.652.D) |
| Fiber Mode | OS2 9/125μm |
| Wavelength | 1310/1550nm |
| Min. Bend Radius (Fiber Core) | 10mm |
| Attenuation at 1310 nm | 0.36 dB/km |
| Attenuation at 1550 nm | 0.22 dB/km |
| Cable Jacket | PVC |
| Polarity | A (Tx) to B (Rx) |
| Storage Temperature | -40~80°C |
Features:
Simplex or duplex or multi fiber assemblies
Riser or Plenum rated, LSZH and cables available
Low insertion loss, IEC, TIA/EIA, Telcordia compliant
Custom fiber optic cable lengths and jacket colors
Various fiber types and wavelengths, typical 9/125 single mode, 50/125 multimode and 62.5/125 multimode
0.9 / 1.8 / 2.0 / 3.0 / mm outer diameter fiber optic cables
PC, UPC, and APC polish types
Good packing, competitive prices and very fast delivery
100% geometry test anc IEC cleaning test are available
OEM service is avaibable
We are aware of the great demanding for the fiber-optic communications technology and product development from the rapidly growing market. And we can only stand out from the fierce market competition through constant innovation and providing customers with good quality of products and services. In addition, we also can be flexible on supporting customers to cater to market demanding, which is one of our effective methods to win market share. In the future, Topstar will continuously adhere to our business philosophy of“Better optical communication, Better world”, and provide our clients with quality products and services!
FAQ
Q1. Can you offer OEM/ODM serivce for those fiber patch cables?
A1:Topstar has rich expiriences inproducing OEM/ODM cases becaused of Profession R & D team
Q2. How does your company do regarding quality control?
A2: we offer 1 year warranty for those fiber accessories;
Q3. What are the trade terms?
A3: Ex-w, COF, CIP, FOB as client requested;
