Product Details:
|
| Rate: | 1.25G | Form Factor: | SFP+ |
|---|---|---|---|
| Reach: | 10Km | Media Type: | SMF |
| Connector Type: | LC | Temperature Range:: | 0 To +70 °C |
| Application: | Gigabit Ethernet | Wavelength: | 1310nm |
| Warrany: | 1 Year | Certification: | ROHS |
| Highlight: | 1.25G Cisco SFP Modules,1310nm Cisco SFP Modules,1310nm Cisco SFP Module |
||
Transceivers 1.25G Optical Modules 1310nm 10Km Cisco SFP Modules Fiber Optic
GLC‐LH‐SMD Features
Highlights SFP transceiver module 100% compatible with Cisco’s equivalent module
Provides 1 Gbps throughput up to 10 km (6.2 mi.) via singlemode fiber cabling
LC duplex female connector supports 1000Base-LX/LH signal at 1310 nm wavelength
Hot-swappable interface lets you install and uninstall without shutting down
Supports DDM for monitoring temperature and other real-time operating parameters
Applications Install an additional LC duplex port on a Cisco router, server or switch for the purpose of connecting a singlemode Gigabit Ethernet network cable
| Rate | 1.25G |
| Reach | 10Km |
| Connector | LC |
| Form Factor | SFP |
| Cabling Type | SMF |
| part number : |
GLC-LH-SMD |
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP is made for Both Multimode and Single-Mode Fibers.
The 1000BASE-LX/LH SFP, compatible with the IEEE 802.3z 1000BASE-LX standard, operates on standard single-mode fiber-optic link
spans of up to 10 km and up to 550 m on any multimode fibers. When used over legacy multimode fiber type, the transmitter should
be coupled through a mode conditioning patch cable. 1300-nm wavelength, extended operating temperature range and DOM
support, dual LC/PC connector.
Features SFP Transceiver Designed for Connection to Your Cisco Network Switch or ServerThis SFP transceiver allows you to connect an 9/125 singlemode fiber optic cable to a 10/100/1000 Mbps network router, server or switch. It transmits data up to 10 kilometers (6.2 miles) and supports bi-directional Gigabit Ethernet communication up to 1.25 Gbps. The metal housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco GLC-LH-SMD Transceiver ModuleThe MSA-compliant N286- 01GLCLHSMD functions just like the equivalent Cisco GLC-LH-SMD transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the GLC-LH-SMD
Supports Digital Diagnostic Monitoring (DDM) for Real-Time Status MonitoringDDM support lets you keep track of various operating statuses in real time, including transceiver temperature, input and output power, and supply voltage .
