G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R

G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R
G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R

Large Image :  G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R

Product Details:
Place of Origin: Czech
Brand Name: Brocade
Certification: CE SA KCC
Model Number: BR-G630-48-32G-R
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Price is negotiable
Packaging Details: 71x62x24cm
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union, MoneyGram, Paypal,Credit Card
Supply Ability: 500pcs per month

G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R

Description
Generation: 6 Fibre Channel Ports: 96 Standard SFP 32Gb/s Capable Ports And 8 QSFP Ports
Aggregate Bandwidth: 4Tb/s Performance: 32Gb/s SFPs Can Operate At 32, 16 Or 8Gb/s
AC Input: 100V To 240V Nominal, 90V To 264V Range. Maximum Input Current: 12A. Power Supply: Two Power Supply FRUs With Integrated Power Module, Voltage Range Of 90V To 264V AC. 80 Plus Platinum.
Weight: 22kg
Highlight:

BR-G630-48-32G-R Brocade G630 Switch

,

G630 Brocade 48 Port Switch

,

48 Port Switch 32G SFP FC

BR-G630-48-32G-R Brocade G630 Switch 48 Port Activation 32G SFP FC Switch



G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R 0

Product Description:

Brocade Gen 6 Fibre Channel is the purpose-built network infrastructure for mission-critical storage, delivering NVMe-ready performance, advanced automation, and comprehensive management to accelerate application performance and drive always-on business operations.

The Brocade G630 Switch with Gen 6 Fibre Channel and Brocade Fabric Vision technology delivers unmatched 32G performance, industry leading port density, andautomated operations to support storage growth, demanding workloads, and data center consolidation.

Simplify andConsolidate Cabling with Flexible Q-Flex Ports
Q-Flex ports are available for flexible Inter-Switch Link (ISL) and device connectivity with industry leading 32G speeds. These ports are designed to support single QSFP connections or fan out to four standard SFP+ connections, enabling administrators to simplify cabling infrastructure. The Ports on Demand (PoD) feature of the Brocade G630 gives organizations the flexibility to mix and add Q-Flex ports at any time.





Main features Systems Architecture
AC Power consumption Maximum 942W with all 128 ports operating at 32G (96 ports populated with 32G SWL optics and 8 QSFP ports populated with 4×32G SWL optics).
Maximum of 495W for empty chassis with no optics in idle configuration
Scalability Full-fabric architecture with a maximum of 239 switches
Operating environment
Temperature: 0°C to 40°C/32°F to 104°F
Humidity: 10% to 85% (non-condensing)
Management access 10/100/1000 Mb/s Ethernet (RJ-45), In-band over Fibre Channel, Serial port (RJ-45), and one USB port
ISL Trunking Enterprise Package - includes Fabric Vision, Extended Fabric and ISL Trunking
USB One USB port for system log file downloads or firmware upgrades
Vibration Operating: 0.5g sine, 0.4 grms random, 5 Hz to 500 Hz
Non-operating: 2.0g sine, 1.1 grms random, 5 Hz to 500 Hz
Enclosure
Front-to-back airflow; non-port-side exhaust; port-side intake; 2U
Back-to-front airflow; non-port-side intake; port-side exhaust; 2U
Port types D_Port (ClearLink Diagnostic Port), E_Port, EX_Port, F_Port, AE_Port, optional port-type control
Media types
32G FC SFP+ LC connector: SWL, LWL, ELWL
16G FC SFP+ LC connector: SWL, LWL, ELWL
10G FC SFP+ LC connector: SWL, LWL
4x32G FC QSFP+ MPO connector: SWL
4x32G FC QSFP+ SMF LC connector: 2 km (fixed at 4x32G only)
4x16G FC QSFP+ MPO connector: SWL
Security DH-CHAP (between switches and end devices), FCAP switch authentication; HTTPS, IP filtering, LDAP with IPv6, OpenLDAP, Port Binding, RADIUS, TACACS+, user-defined Role-Based Access Control (RBAC), Secure Boot, Secure Copy (SCP), Secure Syslog, SFTP, SSH v2, SSL, Switch Binding, Trusted Switch. The Brocade G630 Switch provides up to 12 in-flight encryption and compression ports.
Size
Width: 440.00 mm (17.32 in.)
Height: 86.70 mm (3.41 in.)
Depth: 609.60 mm (24.00 in.)
Heat dissipation 128 ports at 3512 BTU/hr


G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R 1



Data centers are under pressure to deliver maximum performance, business intelligence, and operational efficiency to address exponential data growth and dynamic business demands. To gain the performance required, organizations are transitioning to the all-flash data center, which requires a modern storage network that can keep pace with innovations in compute and storage resources. By modernizing the SAN, organizations will be able to maximize productivity and increase the efficiency of their storage investments, even as they rapidly scale their environments. Moreover, the addition of automation technology to Gen 6 Fibre Channel will transform SAN management by simplifying operations and freeing up resources to focus on business optimization and revenue opportunities.
G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R 2G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R 3G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R 4G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R 5
