Product Details:
|
Form Factor: | SFP | Data Transfer Rate: | 10G |
---|---|---|---|
Distance: | 300M | Cable Type: | MMF |
Wavelength: | 850nm | Supply Power: | 3.3V |
Warranty: | 1 Year | DDM: | Yes |
Highlight: | Finisar SFP 10G XFP Optical Transceiver,XFP Optical Transceiver 850nm Multimode,850nm Multimode Finisar SFP 10G |
Finisar FTLF1424P2BTR Duplex SFP 4.25Gbps 10 Km SMF DDM 1310nm Modules
Optical Module FTLF1424P2BTR Specification
Application | 10Gb/s |
Wavelength | 850 nm |
Optical Extinction Ratio | 5.5dB |
Distance | 300m |
Form Factor | SFP |
Connector | LC |
DDM | Yes |
Certificate | ROHS |
PRODUCT FEATURES
• Up-to 10 km over SMF @ 4.25Gbps
• 1310nm Duplex SFP Transceiver
• -40°C - 85°C Operating Case Temperature
• SFF-8724 Digital optical monitoring
• Hot-swappable for SFP LC ports
• Finisar Standard 1 Year Warranty
• Metal enclosure, for lower EMI
• SFP MSA / IEEE Std 802.3
• Finisar FTLF1424P2BTR is RoHS compliant
• Finisar 4GFC Fibre Channel SFP
Applications
• 4.25 Gb/s Fibre Channel
• 1.25Gb/s Gigabit Ethernet
The Finisar FTLF1424P2BTR 4GFC Fibre Channel transceiver is a Duplex SFP transceiver for optical communications, rated
for distances up to 10 km and a maximum bandwidth of 4.25Gbps. The FTLF1424P2BTR transceiver operates at 1310nm
wavelength. Finisar’s FTLF1424P2xTR and FTLF1424P2xTD Small Form Factor Pluggable (SFP) transceivers are compatible
with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). They are compatible with Fibre Channel per FC-PI-2
Rev. 10.0. Rate selectable versions are also simultaneously compatible with Gigabit Ethernet as specified in IEEE Std 802.3.
The product is RoHS compliant and lead-free per Directive 2002/95/EC and Finisar Application Note AN -2038.
