Product Details:
|
| Wavelength: | 1310nm | Cable Type: | SMF |
|---|---|---|---|
| Commercial Temperature Range: | 0 To 70°C | Extinction Ratio: | >3.5dB |
| Power Consumption: | ≤3.5W | DDM: | Yes |
| Connector: | Duplex LC | Reach: | 2Km |
| Highlight: | Duplex LC Optical Transceiver Module,ROHS QSFP28 100G CWDM4,2km QSFP28 100G CWDM4 |
||
DELL QSFP28-100G-CWDM4 1310nm 2km DOM Duplex LC SMF Optical Transceiver Module
100G QSFP28 Product Features
Features:
Maximum Power Consumption 5.5w
Operating Case Temperature Range: -40 ~ 85℃
Single 3.3V Supply Voltage
LAN WDM EML laser and PIN Receiver Array
QSFP28 MSA Package with Duplex LC Connector
Two Wire Serial Interface with Digital Diagnostic Monitoring
Complies with EU Directive 2011/65/EU (RoHS compliant)
Class 1 Laser
100G QSFP28 Application
For dater center
Standards:
Compliant with QSFP28 Standard -SFF-8665 Revision 1.9 -SFF-8636 Revision 2.10a
Compliant with 100G 4WDM-40 MSA technical specificationrev1.0
| Form Factor | QSFP28 |
| Wavelength | 1310nm |
| 100G QSFP28 Application | 100G Ethernet,5G wireless net |
| DDMI | Support |
| Extinction Ratio | >3.5dB |
| Power Consumption | ≤3.5W |
The 100G QSFP28 Optical Transceiver Module is designed for use in 100Gb/s Ethernet systems throughput up to 40kmover singlemode fiber (SMF) with duplex LC connectors. This transceiver is compliant with SFF-8636, SFF-8665 and 4WDM-40 standard. Digitaldiagnostics functions allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, suchas datacenters,high-performance computing networks, enterprise core and distribution layer applications
QSFP28 100G Description
The Dell QSFP-100G-CWDM4 QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 2km over single mode fiber (SMF). The 100 Gigabit Ethernet signal is carried over four wavelengths at 1271, 1291, 1311, 1331 nm. This transceiver is compliant with IEEE 802.3ba, IEEE 802.3bm, 100G CWDM4 MSA, SFF-8665, SFF-8636 and ITU-T G.694.2 standards. With these features, this is suitable to be used in various applications, such as data centers, high-performance computing networks,enterprise core and distribution layer applications.
FAQ
Q1. Are your Optical Transceivers original?
A1.Yes, all our optical transceivers are guaranteed 100% original!
Q2.How do you guarantee the quality of optical module ?
A2.There are professional testing equipments and QC team. Every unit will be fully tested with perfect performance before shipping.
Q3. What will you do if I found the product has any quality problem?
A3.We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years! Our dream is to build a famous 100 years enterprise!
Q4. What are the trade terms?
A4.Lead Time: 1-3 day after confirm your payment (In stock, we need 1 day to fully test them)
Payment term: Western Union, T/T, Alipay, Escow, Money Gram
Warranty: 1 Year
Q5. Do you have compatible ones?
A5.Yes, we have our own brand:Top-trans, including 1X9,SFP, XFP, SFP+, BIDI in all kinds of specifications.
