Product Details:
|
| Data Rate: | 25Gb/s | Form-Factor: | SFP+ |
|---|---|---|---|
| Center Wavelength: | 850nm | Transmission Distance: | 100m |
| Temperature: | 0℃ To 70℃ | Connector: | Duplex LC |
| Lasers: | VCSEL | Applications: | 25.78 Gb/s Single Lane 100GE SR4 |
| High Light: | 25Gb/S 850nm SFP+ Original SFP Module,FTLF8536P4BNL-E5 850nm SFP+,Original SFP Module FTLF8536P4BNL-E5 |
||
DELL FTLF8536P4BNL-E5 25Gb/s 850nm Short Wavelength SFP+ Transceiver
| Fiber Type | Single mode |
| Weight | 0.06kg |
| Warranty | 1 year |
| Tx power | -9.0 to +2.0 dBm |
| Rx sensitivity | -12.0 to +2.0 dBm |
| Extinction Ratio | 3.5dB |
| Power Consumption | 1.3W |
| Single Power Supply | 3.3V |
FTLF8536P4BCL-E5 SFP+ Module Features
Applications
The Description of FTLF8532P4BNV-E5
Finisar’s FTLF8536P4BCL-E5 SFP+ transceivers are designed for use in 25Gb/s data rate over multimode fiber.
They are compliant to IEEE802.3by, SFF-8472 Rev 12.2b and SFF-8402g, and compatible with SFF-8432a and applicable portions of SFF-8431 Rev. 4.1c.
The transceiver is RoHS compliant and per Directive 2011/65/EUd . See Finisar Application Note AN-2038 for more details.
FAQ
Q1. Are your Optical Transceivers original?
A1.Yes, all our optical transceivers are guaranteed 100% original!
Q2.How do you guarantee the quality of SFP?
A2.We have professional testing equipment and QC team. Every unit will be fully tested with perfect performance before shipping.
Q3. What is the operating temperature range of optical modules?
A3: Commercial temperature range(COM) : 0 to 70°C(32 to 158°F)
Extended temperature range(EXT):-5 to 85°C(23 to 185°F)
Industrial temperature range(IND)::-40 to 85°C(-40 to 185°F)
Storage temperature range:-40 to +85°C(-40 to 185°F)
Q5. What are the trade terms?
A5.Lead Time: 1 day after confirm your payment (In stock, we need 1 day to fully test them)
Payment term: Western Union, T/T, Alipay, Escow, Money Gram
Warranty: 1 Year
